Twitter| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Brand Name | LNV |
| Driven Type | Electric |
| Color | Mint Green & Black |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Condition
New
Automatic Grade
Semi Automatic
Application
Calibration
Classification
Oil Bath Temp. Calibrator
Voltage
220V
Capacity
50 To 250 DegC
Type
High Temperature Oil Bath
Weight
10 Kg Approx
Warranty
1year
Country of Origin
India
Model
SUL-250
Control Range
50 to 250 °C @ 25°C
Resolution
0.1 °C
Control Accuracy
+0.1°C
Thermal Stability
+0.03°C at 50°C, +0.05°C at 100°C, +0.08°C at 250°C
Thermal Uniformity (Radial)
+0.06°C at 50°C, +0.07°C at 100°C, + 0.10°C at 250°C
Stabilization Time/settling time
20 minutes after set point is achieved.
Heating Time
60 Min.( Room Temperature to 250 °C ) @25°C
Cooling Time
120 Min.{ 250 °C to Room Temperature) @25°C
Power Supply
230 V(AC), (50 Hz)
Oil/ Liquid
50 CST Silicon Oil only
Power Consumption
500 Watt
Display
LCD, °C or °F user-selectable
Construction Size (H x W x D)
320(H) x 165(W) x 290(D) mm
Instrument Weight
10 Kg Approx
Environmental operating conditions
0 °C to 50 °C, 0 % to 90 % RH (non-condensing)
Immersion (Well) Depth
150 mm
Insert Length
140 mm
Insert OD
50 mm
Method of Control
Self tunned PID controller
Specifications valid in environmental conditions
S°C ... 25°C
Product Code
SUL-250
Port
Any From India
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Delivery Time
1 To 2 Week
Looking for "LNV SUL-250 Hot Oil Bath Temperature Calibrator" ?
Piece
